Name: FGG EGG LEMO Circular Push Pull Connectors Shock Resistant Corrosion Proof
Brand: Shenzhen Raymo Electronics Technology Limited
SKU: Fgg.00b.302.clad52z
Price: 11.10 USD
Availability: InStock

FGG EGG LEMO 00 0B 1B 2B 3B 4B circular push pull connectors FGG 0B 3022 CLAD

RAYMO P/N	Lemo P/N	DESCRIPTION
RM-FGG-0BC-302-JS**Z	FGG.0BC.302.CLAD**Z	FGG cable mount plug,0B 2pins male solder contacts,nautral shell,52 cable collet with a bend relief

** for cable diameter(32,42,52 are available)

Main Features

100% compatible with LEMO FGG EGG

security of the Push-Pull self-latching system

multipole types 2 to 32 contacts

solder/ print contacts (straight or elbow)

multiple key options to avoid cross mating,such us 30, 45, 60, 90, 135

high packing density for space savings

5000 times push pull

Technical Characteristics
Temperature Range	- 65° C, +200° C	Resistance to vibrations	15 g [10 Hz - 2000 Hz]
Shell Material	Brass with chrome plated	Humidity	up to 95% at 60° C/140F
Shock Resistance	100 g [ 6 ms]	Salt spray corrosion test	>144hr
Climatical Category	50/175/21	Shielding (min)	> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
IP Rating	IP50	Endurance(shell)	5000 mating cycles

SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented circular push pull connector and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers

With professional R&D and excellent craftsmanship, our factory has the ability of offering customer with much more precision connectors and cable harness solution to meet customer's real needs in his field.

RAYMO's high quality connectors are found in a variety of challenging applications and environments including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application.

FGG EGG LEMO Circular Push Pull Connectors Shock Resistant Corrosion Proof 0

Shell size	Contacts no. ( Both with Solder & PCB type )
Shell size	Contacts no. ( Both with Solder & PCB type )
00	2	3	4
0B	2	3	4	5	6	7	9
1B	2	3	4	5	6	7	8	10	12	14	16
2B	2	3	4	5	6	7	8	10	12	14	16	19
3B	3	4	6	8/(6+2)	9(8+1)	10	12	14(13+1)	14	16	18	21	26	30	32
4B	7	10	24

RFQ:

1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing circular connectors and cable assembly since 2010.Our factory is SGS audited manufacturer and worked on www.alibaba.com more than 9 years.
2. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
3. Free sample :
Raymo: Available. Any needs, please contact us.
4. What about the delivery time?
Raymo: sample for 3-5 working days, mass prction for 5-7 working days.
5. What is your payment terms?
Raymo: 100% T/T deposit when customer place order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory
has instruments to tested them before shipping.
Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!

Label:

Tempat asal:	Shenzhen, Cina
Nama merek:	RAYMO
Sertifikasi:	ISO:9001-2015, CE ,RoHS2.0, SGS, REACH
Nomor model:	Fgg.00b.302.clad52z

Kuantitas min Order:	5 potong/potong
Harga:	negotiable
Kemasan rincian:	Kantong Plastik & Karton
Waktu pengiriman:	5-7WDS
Syarat-syarat pembayaran:	Western Union, L/C, D/A, D/P, T/T
Menyediakan kemampuan:	5000Potongan/Minggu

Seri:	Kompatibel dengan Lemo FGG.1B (00B, 0B, 1B, 2B, 3B, 4B tersedia)	Nomor kontak.:	2,3,4,5,6,7,9pins
isolator:	PPS/PEEK	Peringkat IP:	IP50
Ketahanan:	5000 kali mendorong tarik	aplikasi:	Audio & Video
Menyoroti:	electronics component connectors , cable connector plug
