Name: WSO Fischer Military Grade Connectors Waterproof IP68 Protective Grade Functional
Brand: Shenzhen Raymo Electronics Technology Limited
SKU: WSO 102 A051 140+
Price: 12.30 USD
Availability: InStock

WSO Fischer Military Grade Connectors Waterproof IP68 Protective Grade Functional

Informasi Dasar

Tempat asal:	Shenzhen, Cina
Nama merek:	RAYMO
Sertifikasi:	REACH/ CE/ ISO9000:2015/ ROHS/ SGS
Nomor model:	WSO 102 A051 140+

Kuantitas min Order:	5piece/potongan
Harga:	negotiable
Kemasan rincian:	Kantong Plastik & Karton
Waktu pengiriman:	5-7WDS
Syarat-syarat pembayaran:	Western Union, L/C, D/A, D/P, T/T
Menyediakan kemampuan:	10000pieces/ bulan

Hubungi sekarang

Seri:

Konektor Bulat yang Tahan Air

Model shell:

Konektor siku Fischer WSO

Ukuran cangkang:

0F/102,1F/103, AF/1031,2F/104

Nomor kontak.:

2,3,4,5,7,9pins (2-19 psin untuk cangkang lainnya)

Menghubungkan tipe:

PPS/Peek Insulator dengan Kontak Solder

aplikasi:

Tes dan Pengukuran

Menyoroti:

mil spec wire connectors

military cable connectors

WSO Fischer elbow cable connector, waterproof IP68,WSO 102 A051 140 2pins 102 103 1031 104

Parts No.:RM-WSO-0F1S-P02JS50= WSO 102 A051 140+

Description
1	100% substitute with original Fischer WSO elbow cable plug
2	right angle 2pins,male solder contacts with black shellIP68 circular cable connector
3	shell size 102,103,1031 and 104
4	Sealed to IP68 and Hermetic
5	360° EMC shield
6	Available Solder,PCB or right angle PCB contacts
7	Robust and shock resistant designs

RAYMO is a manufacturer that:

♣ Manufacturing & exporting various metal & plastic circular connectors and cable assembly

♣ All prcts can be 100% compatible with original LEMO • FISCHER • • HIROSE • BINDERS and Military 38999

♣ Cable Assembly can be designed according customer real needs

♣ All the prcts we got CE, ROHS, SGS,ISO9000 certificate

♣ OEM connector and Cable assembly

• All the items can work normally after 5000 times mating

We can make all types of cables and connectors as per customers' request. Use any kind of connectors, like Hirose, Cannon, BNC, TNC, D-sub, USB, RJ45, Dtap, JST, Molex, and so on. Just tell us your need, leave the rest to RAYMO

Series	contact no.
0F/102 series	2,3,4,5,6,7,9
1F/103 series	2,3,4,5,6,7,8,10,12
AF/1031 series	10,12,15,19
2F/104 series	2,3,4,5,6,8,16,19

Technical Characteristics
Temperature Range	- 65° C, +200° C	Resistance to vibrations	15 g [10 Hz - 2000 Hz]
Shock Resistance	100 g [ 6 ms]	Salt spray corrosion test	>144hr
Climatical Category	50/175/21	Shielding (min)	> 75 dB [ at 10 MHz] > 40 dB [ at 1 GHz]
IP Rating	IP 68	Certifications	ISO9001 CE ROHS2.0 SGS

WSO Fischer Military Grade Connectors Waterproof IP68 Protective Grade Functional 0

RAYMO's high quality connectors are found in a variety of challenging applications and environments including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application

Why choose us:

100% compatible lemo connector
Help you save at least 50% cost
Cable assembly offer,help you save prction time

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
