Lemo K Series Fpg 9 Contacts Elbow Circular Waterproof Connectors, Natural Color, FPG-0K-309-ClAD52z

Description

Contact Count: 7 - Positions
Contact Type: Sockets
Material Insulator: PPS
fixed receptacle, nut fixing, with key (G), 1K series, multipoles 7 contacts,outer shell in naturalchrome plated brass, PPS insulator, female pcb contacts.

Features

RM-K series has same insualtor and contact configuar as B series
Secure Push-pull Self-locking system
IP66/68
Alignment Key and Polarized Keying System to avoid cross-interface
360° EMC shielding
High density assembly to save space
Available solder, PCB and right angle PCB contact
can be 100% compatible with original lemo connector

Shell size and contacts for option

Shell size	Contacts no. ( Both with Solder & PCB type )
Shell size	Contacts no. ( Both with Solder & PCB type )
RM-0K	2	3	4	5	6	7	9
RM-1K	2	3	4	5	6	7	8	10	12	14	16
RM-2K	2	3	4	5	6	7	8	10	12	14	16	19
RM-3K	3	4	6	8/(6+2)	9(8+1)	10	12	14(13+1)	14	16	18	21	26	30	32
RM-4K	7	10	24

Application

Automotive
Audio-video
Aviation
Communications
Industrial Control
Information Systems
Machines,Medical
Medical
Military

Company information

RAYMO is a manufactuer that:

Focus on manufacturing & exporting various metal & plastic circular push pull connectors, cable assembly.
Can be 100% compatible with original LEMO • •FISCHER• HIROSE • BINDER •Military 38999
Series has RM-B, RM-K, RM-S, RM-F,RM-E,RM-HR10A, RM-P, RM-M4, RM-M12, RM-M16, BNC, B680,
B423 , 38999, 26482
CO, Form A, Form E for customer clearance
CE, ROHS, REACH, ISO:90001-2015, SGS Audited manufacturer
All the items can work normally after 5000times mating

RM-K Series EGG Shell type dimension and pictures

Assembled Inside Circular Power Connector Data Transfer Equipment Components 1

Assembled Inside Circular Power Connector Data Transfer Equipment Components 2

Why you need buy Raymo's compatible connector?

100% compatible lemo connector
Help you save at least 50% cost
Cable assembly offer,help you save prction time
Large stock,short lead time and easy to buy
We can provide OEM/ODM service and cable assembly solution
it has excellent compatibility with many leading supplier
our company has over 9 years experience and strong professional research and development capabilities.Advanced development and management, comprehensice R&D TESTING and highly automatic prction line make our prcts high reliablilyty and high performance.
Our comapny has passed ISO90001,and got CE, REACH, RoHS and SGS certification

FAQ

1. Are your company a professional manufacturer?
Raymo: Yes, we SGS audited manufacturer
2. What is the MOQ?
Raymo: No MOQ limited, depend on customer real needs.
3. Free sample?
Raymo: Available. Any needs, please contact us.
4. What about the delivery time?
Raymo: 3-5 working days for samples, 5-7 working days for mass prction.
5.What is your payment terms?
Raymo: 100% T/T in advance when customer place an order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating, our factory has instruments to tested them before shipping. Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!

Label:

Tempat asal:	Shenzhen, Cina
Nama merek:	RAYMO
Sertifikasi:	REACH, ISO:9001-2015, CE ,RoHS2.0, SGS
Nomor model:	Egg.0k.307.cll

Kuantitas min Order:	1 Piece/Pieces
Harga:	negotiable
Kemasan rincian:	Kantong Plastik & Karton
Waktu pengiriman:	5-7 hari kerja
Syarat-syarat pembayaran:	Western Union, L/C, D/A, D/P, T/T
Menyediakan kemampuan:	5000 buah / minggu

Seri:	Konektor tahan air melingkar	Ukuran cangkang:	0K (1K, 2K, 3K adalah opsi)
Nomor kontak.:	2, 3, 4, 5, 6, 7, 9	Ketahanan:	5000 kali mendorong tarik
aplikasi:	Peralatan transfer data	isolator:	PPS, Peek
Menyoroti:	waterproof dc connector , waterproof cord connector
