Custom Printed Circuit Connectors Fixed Socket Self Latching System Easy Handling

Informasi Dasar
Tempat asal: Cina
Nama merek: RAYMO
Sertifikasi: ISO:9001-2015
Nomor model: EPG.0B.304.CLN
Kuantitas min Order: 1 Piece/Pieces
Harga: negotiable
Kemasan rincian: Kantong Plastik & Karton
Waktu pengiriman: 5-7 hari kerja
Syarat-syarat pembayaran: T/t, paypal, ebay
Menyediakan kemampuan: 5000Potongan/Minggu
Nama prct: konektor PCB Ukuran cangkang: Konektor siku seri 0B
Nomor kontak.: Kontak wanita 4pin Bahan shell: Cuzn
Terminal: PCB isolator: PPS
Menyoroti:

circuit board connectors

,

pcb board connector

Elbow Pcb Contact Pcb Connector EPG.0b.304.Hln 4pin Female Contact For Pcb Board
Connector Details table



Connector Descitption Details:
Shell model Elbow EPG  Shell size 00B 0B 1B
Gender Female Contact No. 2,3,4,5,6,7,8,9,10,12,14 ,
MOQ 1pc Delivery 5-7 working days
Endurance(shell) 5000 mating cycles Humidity up to 95% at 60° C/140F







Technical Characteristics



Technical Characteristics
Temperature Range - 65° C, +200° C Resistance to vibrations 15 g [10 Hz - 2000 Hz]
Shell Material Brass with chrome plated Humidity up to 95% at 60° C/140F
Shock Resistance 100 g [ 6 ms] Salt spray corrosion test >96hr
Climatical Category 50/175/21 Shielding (min) > 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
IP Rating IP 50 Endurance(shell) 5000 mating cycles





RAYMO Company Intrce



As manufacturer located in Shenzhen, focusing on manufacturing connectors and cable assemblies serive more than 150 countries since 2010.
Raymo Connectors is committed to working closely with its customers to equip their application with the most appropriate connector and cable system. Our prct range comprises over 3,000 standard items and we are always prepared to develop customized solutions for specific requests.


PHOTOS



Custom Printed Circuit Connectors Fixed Socket Self Latching System Easy Handling 0



Raymo Exhibition is coming soon

Custom Printed Circuit Connectors Fixed Socket Self Latching System Easy Handling 1


RAYMO Prcts Applicaiton
  • Medical imaging
  • Scientific research,Automation,Test & measurement
  • Avionics,Transport
  • Communication systems, Defense & Security
  • High Speed Camera
  • Batteries
  • Weatherproof applications
RAYMO Certificate
Why Choose Raymo as a supplier?



If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
