4pin Male Circular Push Pull Connectors Harsh Environmental Resistance High Performance

Circular Push Pull Connectors, 4 ways Lemo alternative 0B 1B 2B 3B,Fixed plug, nut fixing FAG.0B.304.CLV

• can be 100% compatible with origina LEMO FAG connectors
• push pull locking system
• Metal connector
• 4pin male cable connector with elbow pins
• used for aviation

• 360° screening for full EMC shielding
• Secure high performance push-pull Self-locking system
• IP50
• 1 key, and 2 key/channels with 30°,40°,60°,80° to avoid cross-iterface
• multipole types 2 to 32 contacts
• High pin density contributing to equipment miniaturization
• Shock resistant designs
• Functional in a wide temperature range from -45°C to +200°C
• Solder, crimp or print contacts (straight or elbow)

• Pulling and inserting times : ＞5000 times
• Humidity : Maximum humidity up to 95% at a temperature of 60 °
• Resistance to vibrations: 15 g [10 Hz - 2000 Hz]
• Shielding (min): > 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
• Shock Resistance : 100 g [ 6 ms]
• Protention Level : IP50
• Salt Cpray Corrosion test: ＞96Hrs
• Terminal Type: solder
• Number of positions: 1-32pins
• Fastensing Type: Push pull
• Shell Material : Brass
• Shell  Colour : natural and blacl chrome plated
• Contact Material: Brass
• Insert Material : PPS , PEEK

• RoHS 2.0
• CE
• SGS
• ISO:9001-2015
• Reach

1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing circular push-pull connectors and cable assembly since 2010
2. What is the MOQ?
Raymo: No MOQ limited, depend on customer real needs.
3. Free sample:
Raymo: Available. Any needs, please contact us.
4. What about the delivery time?
Raymo: 3-5 working days for samples, 5-7 working days for mass prction.
5.What is your payment terms?
Raymo: 100% T/T in advance when customer place an order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating, our factory has instruments to tested them before shipping. Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
