Rumah ProdukKonektor daya tahan airWaterproof Circular Connectors Plated Solder Contact With Black Chorme

Waterproof Circular Connectors Plated Solder Contact With Black Chorme

Waterproof Circular Connectors Plated Solder Contact With Black Chorme
Waterproof Circular Connectors Plated Solder Contact With Black Chorme Waterproof Circular Connectors Plated Solder Contact With Black Chorme Waterproof Circular Connectors Plated Solder Contact With Black Chorme Waterproof Circular Connectors Plated Solder Contact With Black Chorme
Informasi Dasar
Tempat asal: Shenzhen, Cina
Nama merek: RAYMO
Sertifikasi: ROHS CE SGS ISO:9001-2015
Nomor model: RM-FS2-0LAC-309PS50Z
Kuantitas min Order: 1 Piece/Pieces
Harga: negotiable
Kemasan rincian: Kantong Plastik & Karton
Waktu pengiriman: 5-7 hari kerja
Syarat-syarat pembayaran: T/T, L/C, T/T, Serikat Barat
Menyediakan kemampuan: 5000Potongan/Minggu
Hubungi sekarang
Nama prct: Konektor tarik dorong tahan air Model: Steker lurus
Ukuran cangkang: 0L, 1L Jenis: Kompatibel dengan konektor fischers
Bahan shell: Tembaga dengan berlapis krom Warna: Berlapis koki alam/black-chrome
Nomor kontak.: 2-16 pin Ketahanan: 5000 Kali
Peringkat IP: IP68 tahan air Jenis kontak: PCB PCB Solder/Straight/90 °
Port ekspor: Shenzhen, Cina bahan kontak: Kuningan dengan berlapis emas
Kabel yang dirakit atau tidak: Ya
Menyoroti:

outdoor electrical connector

,

waterproof cord connector

Prct Description

RM-L Series  L model straight plug Metal circular push pull connectors

Part No.:

RM-FS2-0LAS-309PS50Z

Prct Description:

0L size plug, FS2 model plug, A key, 9pin male contact, 50 cable collet, with black bend relief, black chrome plated shell in brass





Main Feature



IP68 Waterproof Push pull locking metal connector F-series connector, cable to cable connector, free socket, inline connector

1 Secure high performance IP68 waterproof push-pull Self-locking system
2 can be 100% compatible with original connector
3 can be with different code
4 can plated with white or black chrome,
5 Available solder and PCB or right angle PCB contact.
6 360 angle screening for full EMC shielding.
7 SO:9001-2015, CE ,RoHS2.0, SGS, Reach





Techical Chracteristics





Technical Characteristics
Temperature Range - 65° C, +200° C Resistance to vibrations 15 g [10 Hz - 2000 Hz]
Shell Material Brass with chrome plated Humidity up to 95% at 60° C/140F
Shock Resistance 100 g [ 6 ms] Salt spray corrosion test >144 hr
Climatical Category 50/175/21 Shielding (min) > 95 dB [ at 10 MHz],    > 80 dB [ at 1 GHz]
IP Rating IP 68 Endurance(shell) ≥5000 mating cycles



Prct Photo

Waterproof Circular Connectors Plated Solder Contact With Black Chorme 0



Waterproof Circular Connectors Plated Solder Contact With Black Chorme 1

Shell size Contacts no. ( Both with Solder & PCB type )
0L 2 3 4 5 6 7 　9 　 　 　 　
1L 2 3 4 5 6 7 8 10 14 16
2L 2 3 4 5 6 7 8 10　 12 14 16
  18 19 26 32 　 　 　 　 　 　 　



Our Company



SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented circular push pull connector and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers



RAYMO's high quality connectors are found in a variety of challenging applications and environments including:

Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application.

Our Exhibition
2020.11 Electronica Munich, Germany
2019 9.24-9.26 Testing Expo, Shanghai
2018 11.12-11.15 Electronica Munich, Germany
2017 9.11-9.16 NAB Show,Netherlands
2016 4.11-4.15 HK Fair
2015 10.2-10.7 ICEEB, Brasil
2014 10.11-10.15 HK Fair
2014 4.11-4.15 HK Fair



Why Choose US?





If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
