Elbow Signal Printed Circuit Connectors Push Pull Type 1B 7 Pins Broadcast Application

Informasi Dasar
Tempat asal: Shenzhen, Cina
Nama merek: RAYMO
Sertifikasi: REACH, SGS, RoHS2.0, ISO:9001-2015, CE
Nomor model: EEG.1B.307.CLV
Kuantitas min Order: 5 potong/potong
Harga: negotiable
Kemasan rincian: Kantong Plastik & Karton
Waktu pengiriman: 5-7WDS
Syarat-syarat pembayaran: Western Union, L/C, D/A, D/P, T/T
Menyediakan kemampuan: 5000Potongan/Minggu
Jenis: Konektor sirkuit cetak PCB Ukuran cangkang: 0B, 1B, 2B, 3B, 4B
Kontak: 2 hingga 32 pin Jenis kelamin: Kontak PCB siku betina
isolator: PPS, Peek tersedia Peringkat IP: IP50
Menyoroti:

circuit board connectors

,

pcb board connector

Lemos B series EEG EGG ECG printed Circuit Connectors, 0B to 4B with 2 to 32 ways elbow signal connector



Company Intrce





Custom Service



Description

RAYMO P/N

Lemo P/N

P/N

RM-EGG-1BC-307-KV

EGG.0B.307.CLV

G20L0C-P02



Shell Size and Contact No.



Shell size Contacts no. ( Both with Solder & PCB type )
00 2 3 4
0B 2 3 4 5 6 7 9
1B 2 3 4 5 6 7 8 10 12 14 16
2B 2 3 4 5 6 7 8 10 12 14 16 19
3B 3 4 6 8/(6+2) 9(8+1) 10 12 14(13+1) 14 16 18 21 26 30 32
4B 7 10 24

Technical Characteristics
Temperature Range - 65° C, +200° C Resistance to vibrations 15 g [10 Hz - 2000 Hz]
Shell Material Brass with chrome plated Humidity up to 95% at 60° C/140F
Shock Resistance 100 g [ 6 ms] Salt spray corrosion test >144hr
Climatical Category 50/175/21 Shielding (min) > 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
IP Rating IP50 Endurance(shell) 5000 mating cycles
Applications
Pictures and Dimension

Elbow Signal Printed Circuit Connectors Push Pull Type 1B 7 Pins Broadcast Application 0



Why choose us
  • 8 years focus on connectors
  • Save your costs at least 50%
  • professional teams in R&D,manufacture,quality testing and export sales to make sure your connectors perfect and have relatively low prices
  • customized your own connectors according to your requirement
  • Factory supplier,provide fast delivery and perfect after-sales service you can purchase without scruple.
  • Help customers to make model selection : Just e-mail us and give the prtion information
FAQ
1.Can I order a small list ?
Raymo:Of course, you can.
2.What quote do you offer?
Raymo:FOB , CIF and others ways according the your needs.
3.How transport?
Raymo:Sea Freight, Air Freight and others Express Delivery ways for you.
4.What is the quality of your prcts guarantee?
We have passed ISO9001:2015 Quality Management System Certification, CQM Quality Management System Certification and IQNet Quality Management System Certification, If the quality doesn't accord the standard, you can exchange the goods for free.
5.Do you have after-sales service?
Raymo:Certainly,you can contact us at any time.
