Rumah ProdukKonektor setengah bulan00 0S 1S 2S Series Half Moon Connector Compact Structure Coaxial Locking Durable

00 0S 1S 2S Series Half Moon Connector Compact Structure Coaxial Locking Durable

00 0S 1S 2S Series Half Moon Connector Compact Structure Coaxial Locking Durable
00 0S 1S 2S Series Half Moon Connector Compact Structure Coaxial Locking Durable 00 0S 1S 2S Series Half Moon Connector Compact Structure Coaxial Locking Durable 00 0S 1S 2S Series Half Moon Connector Compact Structure Coaxial Locking Durable
Informasi Dasar
Tempat asal: Shenzhen, Cina
Nama merek: RAYMO
Sertifikasi: CE/ROHS/SGS/ISO:9001-2015
Nomor model: Ffa.1s.304.clad52z
Kuantitas min Order: 1 Piece/Pieces
Harga: negotiable
Kemasan rincian: Kantong Plastik & Karton
Waktu pengiriman: 5-7 hari kerja
Syarat-syarat pembayaran: T/T, Western Union, D/A, D/P, L/C, MoneyGram
Menyediakan kemampuan: 5000Potongan/Minggu
Hubungi sekarang
Nama prct: Konektor tarik dorong setengah bulan Model: FFA Straight Stug
Ukuran cangkang: 00,0s, 1s, 2s Nomor kontak.: 2-10 pin, koaksial
isolator: PPS, Peek Jenis kelamin: laki-laki, perempuan
Warna shell: Cangkang alami atau hitam Peringkat IP: IP50
Jenis kontak: Solder/PCB/90 ° kontak PCB Kabel yang dirakit atau tidak: Ya
Menyoroti:

pcb contacts connector

,

cable elbow connector

Prct Description

RM-S Series  00S 1S 2S 3S series Half-moon type circular push pull connectors with chrome plated FFA plug

Part No.:

FFA.1S.304.CLAD52Z / RM-FFA-1SC-304JS52Z

Prct Description:

1S size half-moon cable mount push pull connector, FFA plug, 4pin male contact, 52 cable collet, nut for a bend relief, natural chrome plated shell in brass



Main Feature



Half-moon type Push pull locking metal connector S-series connector, cable to cable connector, free socket, inline connector

1 Half-moon type Secure high performance push-pull Self-locking system
2 can be 100% compatible with original Lemo connector
3 Half-moon locking, coaxial locking
4 can plated with white or black chrome
5 Available solder and PCB or right angle PCB contact.
6 360° EMC shield
7 Certificate:ISO:9001-2015, CE ,RoHS2.0, SGS, Reach





Technical Chracteristics



Temperature Range - 65° C, +200° C Resistance to vibrations 15 g [10 Hz - 2000 Hz]
Shell Material Brass with chrome plated Humidity up to 95% at 60° C/140F
Shock Resistance 100 g [ 6 ms] Salt spray corrosion test >96hr
Climatical Category 50/175/21 Shielding (min) > 75 dB [ at 10 MHz],    > 40 dB [ at 1 GHz]
IP Rating IP 50 Endurance(shell) ≥5000 mating cycles



Prct Photo

00 0S 1S 2S Series Half Moon Connector Compact Structure Coaxial Locking Durable 0



Contacts



Shell size Contacts no. ( Both with Solder & PCB type )
00 250        　 　 　 　 　 　 　 　 　
0S 250 2 3 4       　 　 　 　 　
1S 250 275 2 3 4 5 6
2S 250 275 2 3 4 5 6 7 8 10
3S 2 3 4 5 6 7 8 10 12 13 14 16 18
