Rumah Produkkonektor push pull melingkarGold Plated FGG EGG 0B 1B IP50 Circular Plug push pull electrical Connector

Gold Plated FGG EGG 0B 1B IP50 Circular Plug push pull electrical Connector

Gold Plated FGG EGG 0B 1B IP50 Circular Plug push pull electrical Connector
Gold Plated FGG EGG 0B 1B IP50 Circular Plug push pull electrical Connector Gold Plated FGG EGG 0B 1B IP50 Circular Plug push pull electrical Connector
Informasi Dasar
Tempat asal: Shenzhen, Cina
Nama merek: RAYMO
Sertifikasi: RoHS2.0, ISO:9001-2015, CE , SGS, REACH
Nomor model: Rm-fgg-*bc-30*-js ** z/rm-egg-*bc-30*-ks
Kuantitas min Order: 1 buah
Harga: negotiable
Kemasan rincian: CTN
Waktu pengiriman: 5-7 hari kerja
Syarat-syarat pembayaran: Western Union, T/T, D/P, D/A, L/C, MoneyGram
Menyediakan kemampuan: 5000 pcs/minggu
Hubungi sekarang
Nama prct: Dorong Tarik Konektor Listrik Ukuran cangkang: 6.4-19mm
Nomor kontak.: 2-30 pin Bahan shell: Kuningan dengan krom alami/hitam berlapis
Perawatan kontak: Berlapis emas Peringkat IP: IP50
Terminal: Solder/cetak/crimp
Menyoroti:

IP50 Circular Plug Connector

,

1B Circular Plug Connector

,

FGG EGG Waterproof Circular Connector

Gold Plated FGG EGG 0B 1B IP50 Circular Plug push pull electrical Connector

100 compatible with Lemo FGG/EGG



FGG.1B.302.CLAD62 = RM-FGG-1BC-302-JS62 .Straight cable plug with key(G), 1B series, 2 contacts male solder contacts, collet for 5.2- 6.2mm diameter cable, nut for without bend relief, IP50.



RM-B series metal circular push pull connector with below features:



Technical Parameter



Temperature Range
-55°C, +250°C
Resistance to vibrations
15 g [10 Hz - 2000 Hz]
Shock Resistance
100 g [ 6 ms]
Salt spray corrosion test
>96hr
Climatical Category
50/175/21
Shielding (min)
> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
IP Rating
IP50
Certifications
ISO9001/ CE/ ROHS2.0/ SGS





About Raymo

We are the manufacturer in Guangzhou, China, established in 2010, which main in metal push pull connectors, medical plastic connectors, camera connectors, waterproof/watertight connectors, quick release connectors, and there cable assemblies. OEM is accepted.



Gold Plated FGG EGG 0B 1B IP50 Circular Plug push pull electrical Connector 0

FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in PE bag and brown cartons.
OEM&ODM is available after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 100% or Alibaba on-line order are both OK.
Q3. How about your delivery time?
A: Generally, it will take 5~7 working days after receiving your advance payment.
Q5. Can you prce according to the samples?
A: Yes, we can prce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
