Male Female IP50 OD12mm Circular Push Pull Connectors 1B Shell

Male Female IP50 OD12mm Circular Push Pull Connectors 1B Shell
Male Female IP50 OD12mm Circular Push Pull Connectors 1B Shell Male Female IP50 OD12mm Circular Push Pull Connectors 1B Shell
Informasi Dasar
Tempat asal: Shenzhen, Cina
Nama merek: RAYMO
Sertifikasi: RoHS2.0, ISO:9001-2015, CE , SGS, REACH
Nomor model: FGG PHG 1B 308
Kuantitas min Order: 1 buah
Harga: negotiable
Kemasan rincian: 100pc/ctn
Waktu pengiriman: 5-7 hari kerja
Syarat-syarat pembayaran: Western Union, T/T, D/P, D/A, L/C, MoneyGram
Menyediakan kemampuan: 5000 pcs/minggu
Hubungi sekarang
Nama prct: Konektor tarik tarik Jenis: Steker
Ukuran cangkang: Seri 1B Nomor kontak.: 8 pin
Terminal: Pateri Peringkat IP: IP50
Menyoroti:

OD12mm Circular Push Pull Connectors

,

IP50 Circular Push Pull Connectors

,

1B 8 Pin Circular Connector

 OD12mm male female cable to cable electrical audio vedio plug socket, 8 pin circular connector

100% compatible with LEMO original FGG PHG 1B 308



PHG.1B.308.CLLD52Z = RM-PHG-1BC-308-KS52Z .Free socket with key(G) and cable collet, 1B series, multipole 8 contacts, outer shell in natural chrome-plated brass, PPS insulator, female solder contacts, collet for 4.2-5.2mm diameter cable, nut with fitting a bend relief, IP50.

About RAYMO

We are specilized in many kinds of alternative connector such as:

1/ LEMO B, K,S, P series

2/ Fishcer core series 102, 103, 1031, 104, 105

3/ Hirose HR10A series

4/ Binder M16 680, 678, 598, 423 series

5/ OEM series

6/ Cable assemblies

RM-B series metal circular push pull connector with below features:



  • Secure high performance push-pull self-locking system
  • High pin density contributing to equipment miniaturization
  • Alignment Key and Polarized Keying System to avoid cross-interface
  • 360° EMC shielding
  • Robust and shock resistant designs
  • Functional in a wide temperature range from -50°C to +250°C
  • Available solder, PCB and right angle PCB contact

Series B metal circular connectors in many size and outer diameter for different applications are designed to be compatible with connector Series B which with a self-latching system for easy operations.

Shell size Contacts no. With Solder & PCB type
00 2 3 4 　 　 　 　 　 　 　 　 　 　 　
0B 2 3 4 5 6 7 9 　 　 　 　 　 　 　
1B 2 3 4 5 6 7 8 10 12 14 16 　 　 　
2B 2 3 4 5 6 7 8 10 12 14 16 19 26 　
3B 3 4 7 8 10 12 14 16 18 21 30 　 　 　



Technical Characteristics
Temperature Range
-55°C, +250°C
Resistance to vibrations
15 g [10 Hz - 2000 Hz]
Shock Resistance
100 g [ 6 ms]
Salt spray corrosion test
>96hrs
Climatical Category
50/175/21
Humidity
Up to 95% at 60°C
IP Rating
IP50
Certifications
ISO9001/ CE/ ROHS2.0/ SGS



Male Female IP50 OD12mm Circular Push Pull Connectors 1B Shell 0

Applications
RAYMO connectors have been widely used in the areas of telecommunication, electronics, medical equipments, aviation, audio-video, petroleum, motor and power industries, electrical signal connection, IC control systems, test and measurement instruments, ect.

Male Female IP50 OD12mm Circular Push Pull Connectors 1B Shell 1
