Binder 581/680 Series M16 Panel Mount Connectors Mini Size PBT Insulator

Binder 581/680 Series M16 Panel Mount Connectors Mini Size PBT Insulator
Binder 581/680 Series M16 Panel Mount Connectors Mini Size PBT Insulator
Binder 581/680 Series M16 Panel Mount Connectors Mini Size PBT Insulator Binder 581/680 Series M16 Panel Mount Connectors Mini Size PBT Insulator
Informasi Dasar
Tempat asal: Shenzhen, Cina
Nama merek: RAYMO
Sertifikasi: RoHs2.0, CE, ISO9001:2015, SGS, Reach
Nomor model: 09-0332-00-12
Kuantitas min Order: 1 Piece/Pieces
Harga: negotiable
Kemasan rincian: Kantong Plastik & Karton
Waktu pengiriman: 5-7 hari kerja
Syarat-syarat pembayaran: T/T, D/A, D/P, L/C, Moneygram, Western Union
Menyediakan kemampuan: 5000Potongan/Minggu
Hubungi sekarang
Nama prct: 680 konektor seri Sistem Penguncian Konektor:: Baut
Nomor kontak.: 2,3, 4, 5, 6,7, 8, 12 isolator: PBT
Bahan shell: Kuningan berlapis -lapis Tingkat perlindungan: IP 40
Operasi mekanis: >500 siklus kawin Nomor tarif bea cukai: 85369010
Menyoroti:

M16 Panel Mount Connectors

,

PBT Insulator Panel Mount Connectors

,

Mini Size M16 Connector

Binder 581/680 Series Panel Mount Mini Connectors M16



 Features and Benefits of M16 680 Series circular connector
Specification of M16 680 Series circular connector​
Attribute Value
Number of Contacts 12
Mounting Type Cable Mount
Connector Size Miniature
Plug/Socket Plug
Termination Method Solder
IP Rating IP40
Contact Gender Male
Current Rating 6.0A
Voltage Rating 250 V
Mating Type Screw Lock
Body Orientation Straight
Series 680
Contact Plating Silver
Minimum Operating Temperature -40°C
Contact Material Brass
Maximum Operating Temperature +85°C



Application of M16 680 Series circular connector​



M16 series connector equivalent as Binder Series 680 678 423, 723 family of connectors are rugged,

high-performance circular connectors with excellent EMI shielding .

Ideal choice for severe industrial and commercial applications. Panel-mounted receptacle are

available in many styles and mounting methods.



Electrical data of M16 680 Series circular connector​



Wire gauge max, 0.75mm²(max. AWG 20) ( 3-8 poles)
max, 025mm²(max. AWG 24) (12 poles )
Cable outlet 3-6mm/6-8mm
Mechanical opera >500 ma
Upper temperature + 85 °C
Lower temperature – 40 °C
Rated voltage 250 V (32 V) 2-4 poles
60 V (32 V) 5 poles
250 V (32 V) 6poles
125V (32 V) 7poles
60 V (32 V), 8-12poles
Rated impulse voltage 1500V 2-6poles
800V 7 poles
500V (32 V)8-12poles
Rated current (40 °C) 7A 2-3 poles
6A 4-6 poles
5A 7-8poles
3A 12poles
Contact resistance ≤ 5 MΩ 3-8 poles
　 ≤ 3 mΩ 12poles




RAYMO Company Intrce



SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented metal and plastic circular push-pull self-latching connectors and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers.

This vast portfolio enables you to select the ideal connector configuration to suit almost any specific requirement in most markets inclyding medical devices, test and measurement instruments, machinery, audio video broadcast, telecommunications and military



Chooseing tips of M16 680 Series circular connector​
  • If you have ordered this shell connector and know the original model P/N,
  • please tell us.We will directly offer you our correspinding one.
  • If you don't know much about the connector,please make choose according the following factors
  • The use of enviroment,indoor or ourdoors,waterproof or not
Why choose us
Pictures of M16 680 Series circular connector​

Binder 581/680 Series M16 Panel Mount Connectors Mini Size PBT Insulator 0





If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
