Rumah ProdukKonektor tahan air melingkarS SS 102 103 1031 104 cable IP68 waterproof connectors,Fischer connector,2pins SS 102 A051 130+

S SS 102 103 1031 104 cable IP68 waterproof connectors,Fischer connector,2pins SS 102 A051 130+

S SS 102 103 1031 104 cable IP68 waterproof connectors,Fischer connector,2pins SS 102 A051 130+
S SS 102 103 1031 104 cable IP68 waterproof connectors,Fischer connector,2pins SS 102 A051 130+ S SS 102 103 1031 104 cable IP68 waterproof connectors,Fischer connector,2pins SS 102 A051 130+ S SS 102 103 1031 104 cable IP68 waterproof connectors,Fischer connector,2pins SS 102 A051 130+ S SS 102 103 1031 104 cable IP68 waterproof connectors,Fischer connector,2pins SS 102 A051 130+ S SS 102 103 1031 104 cable IP68 waterproof connectors,Fischer connector,2pins SS 102 A051 130+
Informasi Dasar
Tempat asal: Shenzhen, Cina
Nama merek: RAYMO
Sertifikasi: ISO9000:2015/ CE/ ROHS/ SGS/ REACH
Nomor model: SS-0F1C-P02JS50
Kuantitas min Order: 5piece/potongan
Harga: negotiable
Kemasan rincian: Kantong Plastik & Karton
Waktu pengiriman: 5-7WDS
Syarat-syarat pembayaran: Western Union, L/C, D/A, D/P, T/T
Menyediakan kemampuan: 5000Potongan/Minggu
Hubungi sekarang
Jenis: Fischer Circular Push Pull Connector Model shell: Steker pemasangan kabel pendek ss
Ukuran cangkang: 0F/102 Nomor kontak.: 2,3,4,5,7,9pins
Warna: Krom alami / hitam Menghubungkan tipe: Kontak Solder dengan PPS/Peek Insulator
aplikasi: Audio & Video Peringkat IP: IP68
Menyoroti:

waterproof wire connectors

,

waterproof electrical connectors

S SS 102 103 1031 104 cable IP68 waterproof connectors,Fischer connector,2pins SS 102 A051 130+



Parts No.:RM-SS-0F1C-P03JS50= SS 102 A051 130+

Description:Compatible Fischer SS 102 2 Pin Circular Connector, male plug,solder type, natural chrome plated brass , 50 cable collet



Features
1 100% substitute with original Fischer
2 different shell size is available from 102,103,1031 and 104
3 Sealed to IP68 and Hermetic
4 360° EMC shield
5 Available Solder,PCB or right angle PCB contacts
6 Robust and shock resistant designs



Series

contact no.

0F/102 series

2,3,4,5,6,7,9

1F/103 series

2,3,4,5,6,7,8,10,12

AF/1031 series

10,12,15,19

2F/104 series

2,3,4,5,6,8,16,19



RAYMO is a manufacturer that:

♣ Manufacturing & exporting various metal & plastic circular connectors and cable assembly

♣ All prcts can be 100% compatible with original LEMO • FISCHER •  • HIROSE • BINDERS and Military 38999

♣ Cable Assembly can be designed according customer real needs

♣ All the prcts we got CE, ROHS, SGS,ISO9000 certificate

♣ OEM connector and Cable assembly

• All the items can work normally after 5000 times mating

We can make all types of cables and connectors as per customers' request. Use any kind of connectors, like Hirose, Cannon, BNC, TNC, D-sub, USB, RJ45, Dtap, JST, Molex, and so on. Just tell us your need, leave the rest to RAYMO



S SS 102 103 1031 104 cable IP68 waterproof connectors,Fischer connector,2pins SS 102 A051 130+ 0

S SS 102 103 1031 104 cable IP68 waterproof connectors,Fischer connector,2pins SS 102 A051 130+ 1



Technical Characteristics
Temperature Range - 65° C, +200° C Resistance to vibrations 15 g [10 Hz - 2000 Hz]
Shock Resistance 100 g [ 6 ms] Salt spray corrosion test >144hr
Climatical Category 50/175/21 Shielding (min) > 75 dB [ at 10 MHz]
> 40 dB [ at 1 GHz]
IP Rating IP 68 Certifications ISO9001 CE ROHS2.0 SGS



RAYMO's high quality connectors are found in a variety of challenging applications and environments including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application


Why choose us:

  • 100% compatible lemo connector
  • Help you save at least 50% cost
  • Cable assembly offer,help you save prction time



If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!



Label:

konektor kabel tahan air

Konektor Listrik Tahan Air

Konektor Kawat Tahan Air
