Rumah ProdukKonektor tahan air melingkarCompact Waterproof Cable Connector Silicone Sealing High Tensile Compressive Strength

Compact Waterproof Cable Connector Silicone Sealing High Tensile Compressive Strength

Compact Waterproof Cable Connector Silicone Sealing High Tensile Compressive Strength
Compact Waterproof Cable Connector Silicone Sealing High Tensile Compressive Strength
Compact Waterproof Cable Connector Silicone Sealing High Tensile Compressive Strength Compact Waterproof Cable Connector Silicone Sealing High Tensile Compressive Strength
Informasi Dasar
Tempat asal: Shenzhen, Cina
Nama merek: RAYMO
Sertifikasi: CE/ROHS/SGS/ISO:9001-2015
Nomor model: Phg.2kc.319.clld52z
Kuantitas min Order: 1 Piece/Pieces
Harga: negotiable
Kemasan rincian: Kantong Plastik & Karton
Waktu pengiriman: 5-7 hari kerja
Syarat-syarat pembayaran: T/T, Western Union, D/A, D/P, L/C, MoneyGram
Menyediakan kemampuan: 5000Potongan/Minggu
Hubungi sekarang
Nama prct: IP68 Waterproof Push Pull Connector Model: Soket pemasangan kabel phg
Nomor kontak.: 2-32 pin Ukuran cangkang: 0K, 1K, 2K, 3K
Warna shell: Cangkang alami atau hitam isolator: PPS, Peek
Jenis kelamin: laki-laki, perempuan Jenis kontak: Solder/PCB/90 ° kontak PCB
Peringkat IP: IP68 Kabel yang dirakit atau tidak: Ya
Menyoroti:

waterproof electrical connectors

,

waterproof cable connector

Prct Description

RM-K Series  0K 1K 2K 3K series PHG cable mount sokcet

Part No.:

PHG.2K.319.CLLD52Z/ RM-PHG-2KC-319KS52Z

Prct Description:

2K size connector, PHG cable mount socket, 19pin female contact, 52 cable collet, nut for a bend relief, natural chrome plated shell in brass



K series Push pull locking metal connector, cable to cable connector, free socket, inline connector

Main Futures
1 Waterproof Secure high performance push-pull Self-locking system
2 100% compatible with original Lemo K series connector
3 can plated with white or black chrome
4 2-32pin available
5 Available solder and PCB or right angle PCB contact.
6 360° EMC shield
7 Certificate:ISO:9001-2015, CE ,RoHS2.0, SGS, Reach





Technical Characteristics
Temperature Range - 65° C, +200° C Resistance to vibrations 15 g [10 Hz - 2000 Hz]
Shell Material Brass with chrome plated Humidity up to 95% at 60° C/140F
Shock Resistance 100 g [ 6 ms] Salt spray corrosion test >144hr
Climatical Category 55/175/21 Shielding (min) > 95dB [ at 10 MHz],     > 80 dB [ at 1 GHz]
IP Rating IP 68 Endurance(shell) ≥5000 mating cycles





Compact Waterproof Cable Connector Silicone Sealing High Tensile Compressive Strength 0

Shell size Contacts no. ( Both with Solder & PCB type )
0K 2 3 4 5 6 7 9 　 　 　 　 　
1K 2 3 4 5 6 7 8 10 12 14 16 　
2K 2 3 4 5 6 7 8 10 12 14 16 19
3K 3 4 6 8 9 10 12 14 14 16 18 21
26 30 32 　 　 　 　 　 　 　 　 　



Our Company



RAYMO's high quality connectors are found in a variety of challenging applications and environments including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application

Our Exhibition

2020.11 Electronica Munich, Germany
2019 9.24-9.26 Testing Expo, Shanghai
2018 11.12-11.15 Electronica Munich, Germany
2017 9.11-9.16 NAB Show,Netherlands
2016 4.11-4.15 HK Fair
2015 10.2-10.7 ICEEB, Brasil
2014 10.11-10.15 HK Fair
2014 4.11-4.15 HK Fair

Why Choose US?

Compact Waterproof Cable Connector Silicone Sealing High Tensile Compressive Strength 1

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
