Name: Customized 2K Size 16 Pin Male Female Connector Self Locking Metal Harness
Brand: Shenzhen Raymo Electronics Technology Limited
SKU: Rm-hgg.2kc.319.ks
Price: 11.98 USD
Availability: InStock

Customized 2K Size 16 Pin Male Female Connector Self Locking Metal Harness

Informasi Dasar

Tempat asal:	Shenzhen, Cina
Nama merek:	RAYMO
Sertifikasi:	CE/ROHS/SGS/ISO:9001-2015
Nomor model:	Rm-hgg.2kc.319.ks

Kuantitas min Order:	1 Piece/Pieces
Harga:	negotiable
Kemasan rincian:	Kantong Plastik & Karton
Waktu pengiriman:	5-7 hari kerja
Syarat-syarat pembayaran:	T/T, Western Union, D/A, D/P, L/C, MoneyGram
Menyediakan kemampuan:	5000Potongan/Minggu

Hubungi sekarang

Nama prct:

IP68 Waterproof Push Pull Connector

Model:

Soket pemasangan panle hgg

Nomor kontak.:

2-32 pin

Ukuran cangkang:

0K, 1K, 2K, 3K

Warna shell:

Cangkang alami atau hitam

Jenis kelamin:

laki-laki, perempuan

isolator:

PPS, Peek

Jenis kontak:

Solder/PCB/90 ° kontak PCB

Kabel yang dirakit atau tidak:

Peringkat IP:

IP68

Menyoroti:

waterproof electrical connectors

waterproof cable connector

Prct Description

RM-K Series 0K 1K 2K 3K series PHG cable mount sokcet

Part No.:	HHG.1K.308.CLL/ RM-HGG-2KC-319KS
Prct Description:	2K size connector, HGG panel mount socket, 19pin female contact, natural chrome plated shell in brass

K series Push pull locking metal connector, cable to cable connector, free socket, inline connector

Main Futures
1	Waterproof Secure high performance push-pull Self-locking system
2	100% compatible with original Lemo K series connector
3	can plated with white or black chrome
4	2-32pin available
5	Available solder and PCB or right angle PCB contact.
6	360° EMC shield
7	Certificate:ISO:9001-2015, CE ,RoHS2.0, SGS, Reach

Technical Characteristics
Temperature Range	- 65° C, +200° C	Resistance to vibrations	15 g [10 Hz - 2000 Hz]
Shell Material	Brass with chrome plated	Humidity	up to 95% at 60° C/140F
Shock Resistance	100 g [ 6 ms]	Salt spray corrosion test	>144hr
Climatical Category	55/175/21	Shielding (min)	> 95dB [ at 10 MHz], > 80 dB [ at 1 GHz]
IP Rating	IP 68	Endurance(shell)	≥5000 mating cycles

Customized 2K Size 16 Pin Male Female Connector Self Locking Metal Harness 0

Shell size	Contacts no. ( Both with Solder & PCB type )
Shell size	Contacts no. ( Both with Solder & PCB type )
0K	2	3	4	5	6	7	9
1K	2	3	4	5	6	7	8	10	12	14	16
2K	2	3	4	5	6	7	8	10	12	14	16	19
3K	3	4	6	8	9	10	12	14	14	16	18	21
3K	26	30	32

Our Company

RAYMO's high quality connectors are found in a variety of challenging applications and environments including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application

Our Exhibition

2020.11	Electronica Munich, Germany
2019 9.24-9.26	Testing Expo, Shanghai
2018 11.12-11.15	Electronica Munich, Germany
2017 9.11-9.16	NAB Show,Netherlands
2016 4.11-4.15	HK Fair
2015 10.2-10.7	ICEEB, Brasil
2014 10.11-10.15	HK Fair
2014 4.11-4.15	HK Fair

RAYMO Prcts Applicaiton

Medical imaging
Scientific research,Automation,Test & measurement
Avionics,Transport
Communication systems, Defense & Security
High Speed Camera
Batteries
Weatherproof applications

RAYMO Certificate

RoHS 2.0
CE
SGS
ISO:9001-2015
Reach

Why Choose Raymo as a supplier?

Easy mating, can be blind-mated guiding mechanism ensures precise alignment
Increased safety and user friendliness mechanical and color coding prevent misconnection
Increased equipment life span guiding mechanism optimally protects the contacts
Robust and shock resistant designs ideal for equipment used in the field
High performance connectors designed and tested to withstand extreme conditions
Sealed up to IP50 and corrosion resistant usable underwater
Sterilizable ideal for medical applications
Functional in a wide temperature range from -65°C to +200°C
