Name: PPS 102 Shell Waterproof Circular Connector For Communication Systems
Brand: Shenzhen Raymo Electronics Technology Limited
SKU: WSO 102 A052 140
Price: 11.98 USD
Availability: InStock

PPS 102 Shell Waterproof Circular Connector For Communication Systems

Informasi Dasar

Tempat asal:	Shenzhen, Cina
Nama merek:	RAYMO
Sertifikasi:	ISO:9001-2015, REACH, SGS, CE, ROhS
Nomor model:	WSO 102 A052 140

Kuantitas min Order:	1 Piece/Pieces
Harga:	negotiable
Kemasan rincian:	Kantong Plastik & Karton
Waktu pengiriman:	5-7 hari kerja
Syarat-syarat pembayaran:	T/T, Western Union, D/A, D/P, L/C, MoneyGram
Menyediakan kemampuan:	5000Potongan/Minggu

Hubungi sekarang

Nama prct:

Konektor dorong tarik melingkar

Ukuran cangkang:

102 / 0F

Nomor kontak.:

4 pin

isolator:

PPS, Peek

Warna shell:

Krom hitam krom perak

Peringkat IP:

IP68

Menyoroti:

102 Shell Waterproof Circular Connector

PPS Waterproof Circular Connector

IP68 Waterproof Cord Connector

Prct Description

Fischers WSO cable connector to S connector 102 103 1031 shell size for Communication systems

Part No.:	WSO 102 A053 140 = RM-WSO-0F1S-P04JS50
Prct Description:	Circular cable connector WSO to cable S connector, all cable length can be specificed accoding customer real needs

Features:

All different shell size is available from 102 ,103,1031 until 104.

Mutipoles contacts from 2 pin 3 pin 4 pin 5 pin 6 pin 7 pin 8 pin 10 pin 12 pin 14 pin 16 pin 19 pin

Technical Characteristics

Temperature Range	- 65° C, +200° C	Resistance to vibrations	15 g [10 Hz - 2000 Hz]
Shell Material	Brass with chrome plated	Humidity	up to 95% at 60° C/140F
Shock Resistance	100 g [ 6 ms]	Salt spray corrosion test	>96hr
Climatical Category	50/175/21	Shielding (min)	> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
IP Rating	IP 68	Endurance(shell)	≥5000 mating cycles

Our Company

RAYMO ELECTRONICS TECHNOLOGY LTD , established in 2010, located in shenzhen,China

Expert in making high quality push pull connector & cable assemble.
Promotion items with more than 10 years’ experience!
Our goal is to provide customers with the best service possible and to prce excellent quality.
Brand identification prcts will meet or exceed your expectations.
All items coming with certification and we have excellent team offering best connector solution for your application.

RAYMO's high quality connectors are found in a variety of challenging applications and environments Applications

Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application

Our Exhibition

2020.9.14-16	Testing Expo, Shanghai
2019 9.24-9.26	Testing Expo, Shanghai
2018 11.12-11.15	Electronica Munich, Germany
2017 9.11-9.16	NAB Show,Netherlands
2016 4.11-4.15	HK Fair
2015 10.2-10.7	ICEEB, Brasil
2014 10.11-10.15	HK Fair
2014 4.11-4.15	HK Fair

Why Choose US?

100% compatible with lemo, , fischer connector
All the prcts we got CE, ROHS, SGS,ISO9000 certificate
Help you save at least 50% cost
Fast delivery: 2-15 working days
Cable assembly offer, help you save prction time
CE, ROHS2.0, SGS, ISO, Reach

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
